Specifications
Rated Frequency: 50Hz
Rated Power: 4.5kva
Max Power: 5.0kva
Rated Voltage: 110V/220V
Rated Current: 39.1/19.6 A
Rated Rotation Speed: 3000 r/min
Pole No.: 2
Phase: Single Phase
Excitation Mode: Self-excitation and constant voltage (with I-AVR)
Power Factor: 1.0
Insulation Grade: F
Engine Type: RD186FAGET
Structure Type: Single-cylinder, vertical, 4-stroke, air-cooled, direct-injected
Bore x stroke: 86mm x 72mm
Displacement: 0.418L
Compression Ratio: 19:1
Rated Power: 5.7kw
Lubrication System: Pressure Splashed
Lube oil brand: Above CD or SAE 10W-30, 15W-40
Lube Capacity: 1.65L
Starting System: 12V Electric Starter
Charging Generator Capacity: 12V 36AH
Fuel consumption ration: 260.8 g/kW.h
Fuel Type: Diesel: 0# (summer), -10# (winter), -35# (chillness)
Panel: General Panel
Noise Level: 72dB(A)
Fuel Tank Capacity: 15L
